Power Quality, Insulation and Ground Resistance Testers Cut costs and stay safe. Improving energy efficiency, reducing downtime, and prolonging the life of your equipment are some of the ways you can save money with Amprobe tools. Personal computers, photocopiers and fluorescent lighting are all putting greater power demands on facilities. When power becomes distorted or “dirty”, it can very quickly destroy mission critical equipment. Ensuring you have clean energy to support your equipment and avoid costly downtime has become increasingly important

Amprobe AMB-45 Digital Megohmmeter Insulation Resistance Tester

• Tests insulation of wires, cables, transformers and electrical motors
• Comes as a complete kit including test leads and PC software
• Selectable test voltages 250V, 500V and 1000V
• Programmable timer to perform the Dielectric Absorption Ratio Test
• Sensitive Ohmmeter for checking resistance of motor windings
• Built in voltmeter
• Fast and easy to use, rugged durable design
• Internal memory to store measurements for future reference
• Data download to PC
• Limited Life Time Warranty

Spesifikasi – Amprobe AMB-45 Digital Megohmmeter Insulation Resistance Tester

• Display:  70 x 46mm LCD with 60 segment analog bar Indicator.
• Over range Indication:  “OL” will be shown on the LCD Panel when an out of range measurement is made.
• Low Battery Indication:  The symbol is displayed indicating a low battery condition.
• Sampling Rate:  2.5 times/sec Digital Display; 10 times/sec Bar Graph
• Power Source: 1.5V AA size Battery X 8
• Operating Temperature and Humidity:  0 °C to 40 °C ( 32 °F to 104 °F ), below 80% RH
• Storage Temperature: -10 °C to 60 °C ( 14 °F to 140 °F )
• Dimension: 230 x 116 x 62 mm ; 9 x 4.6 x 2.4 inch
• Weight: Approx. 750g(with battery)
• Accessories:  Test Lead, Large Jaw Alligator Clips, Batteries, Instruction Manual, Carrying Case, software, RS-232 cable.
• Insulation resistance with 250, 500& 1000VDC test voltages:  0-4.000/40.00/400.0/4000MΩ ±3% Rdg ± 5 LSD < 2GΩ ±5% Rdg ± 5 LSD <4GΩ
• Low resistance:  0- 400.0, 4000Ω 1% Rdg + 5 LSD
• AC/DC Voltage:  0.1 – 600.0V ±1.5% Rdg ± 5 LSD
• UPC/DCI:  11950
• Warranty: 1 year
• Weight:  1.65 lb
• Safety:  CAT III 600V
