Harga Jual Datum-Y Data Logger / Portable Data Station

Founded in 1915, Yokogawa has nearly 100 years of experiences in the area of power analysis and measurement. During this century, Yokogawa has provided customers with state-of-the-art products to a wide range of different industries.

Yokogawa’s growth throughout the twentieth century has made it become the world’s leader in power analysis. Instruments including digital multimeters and clamp-on testers have been manufactured to the highest specification and quality.

All of Yokogawa’s products can be relied on for safety and reliability. They all comply with the latest safety standards including CE, CSA and UL.

We supply all of Yokogawa’s power analyser range such as the CW Power Meter series and the CA Handy Calibrators.

World first in measuring instruments! We are the first to obtain IPv6 Ready Logo Phase-1(ID:01-000273). Portable size (155x155x55mm) and lightweight (approx. 800g) lets you carry with one hand. Use of a color TFT LCD with wide viewing angle.

Features

  World first in measuring instruments! Obtained IPv6 Ready Logo Phase-1 (ID:01-000273)
  Portable size (155x155x55mm) and lightweight (approx. 800g) lets you carry with one hand
  Wide viewing angle TFT-LCD
  Best noise resistance performance in the category of handheld instruments
  Improves resistance to impact by use of rubber boots (standard accessory)
  Web server, FTP server/client and e-mail distribution function are equipped as standard
  Auto set & Auto run function by inserting external memory
  Alarm, Statistical operation and external function

Specifications

  Terminal shape: Push-lock screw (XL121, XL122), M3 screw (XL124) RTD for XL121 and XL122 only
  Number of inputs: 8 channels (XL121), 16 channels (XL122, XL124)
  Measurement interval: 100ms (8-channel terminal block is used) ~ 1h/200ms (16-channel terminal block is used) ~ 1h
  Storage: Internal memory 16MB/External storage in Compact flash memory card (Type II), SD card USB memory. (Only the copy function is supported by USB memory)
  Input(Range): DCV(100mV~50V, 1-5V f.s.), TC(K,E,J,T,L,U,N,W,R,S,B)/RTD (Pt100, JPt100), Digital (Pulse, Logic)/RTD for XL121 and XL102 only
  Functions: Alarm output (4ch), Trigger function (pre-trigger/triggerdelay), Calculation (Four arithmetic operations between 2 channels, Linear scaling,Statistical operation), Average function, Automatic Measurement function
  Communication function: LAN, USB, RS-232, RS-485

General Specifications

  Operating temperature/humidity range: 0 to 50degC, 5 to 85%RH (no condensation)
  Storage temperature/humidity range: -20 to 60degC, 90%RH or less (no condensation)
  Size: Approx. 155 (W) x 155 (H) x 55 (D) mm (Without projecting parts and rubber boots)
  Weight: Approx. 800g (Without battery and rubber boots)
  Safety standard: EN61010-1/Measurement Category I (Max. Input voltage: 30VDC) Pollution degree 2
  EMC(emission): EN61326 Class A, EN61000-3-2,EN61000-3-3, EN55011 Class A Group1
  EMC(immunity): EN61326 Annex A
  Standard Accessories: Terminal block: 8 channels (95052) or 16 channels (95053,95055), AC adaptor: 100-240V 50/60Hz, Rubber boots: Impact-resistant (93036), Screwdriver: For push-lock screw, Quick manual, CD-ROM (Standard software, USB driver and manuals)
  Accessories: Type-K TC (90060), Carrying case (93037), Lithium ion battery (94009), Stand (93039), Digital I/O cable (91029), RS-232 communication cable (91011), Printer (97010)
