Harga Jual SEW Digital Multimeters 6410 DM

Kode	:	6410 DM
Berat	:	500 gram
Stok	:	Ready Stock
Kondisi	:	Baru
Kategori	:	Alat Ukur
Dilihat	:	2.564 kali
Review	:	Belum ada review

Hubungi kami secara langsung untuk pemesanan yang lebih cepat!

*Pemesanan dapat langsung menghubungi kontak di bawah ini:

*Harga Hubungi CS

Ready Stock / 6410 DM

INFO HARGA
Silahkan menghubungi kontak kami untuk mendapatkan informasi harga produk ini.

Bagikan informasi tentang Harga Jual SEW Digital Multimeters 6410 DM kepada teman atau kerabat Anda.

Deskripsi Harga Jual SEW Digital Multimeters 6410 DM

FEATURES

● 3000 counts with a maximum display of 2999.
● Angled display design helps the user to identify the
reading of value easier.
● Auto scanning function for AC/DC voltage, and current.
● Auto ranging.
● Range change function.
● Continuity check.
● Diode & Capacitance measurement.
● Data hold function.
● Low battery indication.
● Over range indication.
● Fuse protection.
● Special hook design used to hang the meter for ease of use.

SPECIFICATIONS

DC Voltage
Ranges	Resolution	Accuracy		Input protection
300.0mV	100μV	±(0.5%rdg+3dgt)		1000V DC
3.000V	1mV
30.00V	10mV
300.0V	100mV
1000V	1V
․Input impedance : 10MΩ
AC Voltage
Ranges	Resolution	Accuracy		Input protection
300.0mV	100μV	±(1%rdg+5dgt)		800V AC
3.000V	1mV
30.00V	10mV
300.0V	100mV
750V	1V
․Input impedance : 10MΩ
DC Current
Ranges	Resolution	Accuracy		Input protection
300.0μA	0.1μA	±(1%rdg+5dgt)		500mA
3000μA	1μA
30.00mA	0.01mA
300.0mA	0.1mA
10A	10mA	±(2%rdg+3dgt)		12.5A
․Overload Protection 0.5A/250V fast blow fuse for 300mA 12.5A/500V fast blow fuse for 10A
AC Current
Ranges	Resolution	Accuracy		Input protection
300.0μA	0.1μA	±(1%rdg+5dgt)		500mA
3000μA	1μA
30.00mA	0.01mA
300.0mA	0.1mA
10A	10mA	±(2%rdg+3dgt)		12.5A
․Overload Protection 0.5A/250V fast blow fuse for 300mA 12.5A/500V fast blow fuse for 10A
Resistance
Ranges	Resolution	Accuracy	Max test current	Max open circuit voltage
300.0Ω	0.1Ω	±(1.5%rdg+3dgt)	0.51mA	0.39V
3000Ω	1Ω
30.00kΩ	10Ω
300.0kΩ	100Ω
3.000MΩ	1kΩ
30.00MΩ	10kΩ	±(2%rdg+4dgt)
․Overload Protection 500V DC
Frequence
Ranges	Resolution	Accuracy
3.000kHz	1Hz	±(1.0%rdg+2dgt)
30.00kHz	10Hz
100.0kHz	100Hz
Continuity
Ranges	Resolution	Continuity beeper		Test current
300Ω	0.1Ω	< 30Ω		0.51mA
Capacitance
Ranges	Resolution	Accuracy
3000pF	1pF	±(3%rdg+10dgt)
30nF	10nF
300nF	100nF
3μF	1nF
30μF	10nF
300μF	100nF
3mF	1µF
30mF	10µF
GENERAL
Low battery indication		“BATT”
Operating temperature		0ºC ~ 40ºC, 80% Max.
Storage temperature & humidity		-10ºC ~ 50ºC, 80% Max.
Dimensions		192(L) × 88.5(W) × 45(D)mm
Weight (battery included)		Approx. 345g
Power source		1.5V (AAA) × 2
Safety standard		EN 61010-1 CAT III 600V EN 61326-1
