Omano OM900-T Inverted Trinocular Biological Microscope

Overview of Omano OM900-T Inverted Trinocular Biological Microscope

• Inverted biological/phase contrast microscope
• 3 premium plan objectives (PL10x, PL25x, PL40x)
• Plus 1 phase contrast objective (10x)
• 2 sets eyepieces – WF10x and WF16x
• Included phase annulus ring and filters
• LWD 0.4 NA condenser
• Full professional features
• Lifetime Limited Warranty

Summary of Omano OM900-T Inverted Trinocular Biological Microscope

The Omano OM900-T Inverted Trinocular Biological Microscope is a good quality inverted, trinocular biological microscope at a competitive price. It is designed for life science applications where specimens need to be viewed in a container such as a petri dish rather than a slide. The OM900-T accommodates containers up to 2mm thickness and 100mm in height. The microscope features a trinocular viewing head for photomicrography with a C-Mount trinocular adapter and two sets of eyepieces. Lifetime Limited Warranty.

Optics of Omano OM900-T Inverted Trinocular Biological Microscope

The OM900-T includes two sets of eyepieces, WF10x/18mm and WF16x/1mm for strain-free viewing. A diopter enables individual eye focusing and the interpupillary adjustment range is 55mm-75mm. There are four long working distance objectives, three of which are premium plan achromatic( PL10x, PL25x, PL40x), and one is a Phase Contrast PLL10x PHP objective. A phase annulus ring is also included.
The objectives are set in a quadruple inverted nose piece with magnification settings that include: 100x, 160x, 250x, 400x and 640x. A dovetail C-Mount trinocular port also includes a smooth 23mm adapter for an eyepiece camera. The smooth port is compatible with Optixcam cameras and the Meiji MA151/35/03 C-Mount adapter.

Stage & Focus of Omano OM900-T Inverted Trinocular Biological Microscope

A large XY mechanical stage measures 200mm x 152mm with a 78mm x 36mm range of movement. The stage is controlled by convenient, low position coaxial coarse/fine controls with 0.002mm minimum gradations. Rack and pinion focusing includes dual sided, coaxial coarse/fine focus controls with gradations on the right hand side.

Condenser & Illumination of Omano OM900-T Inverted Trinocular Biological Microscope

The above stage condenser is a long working distance (30mm) 0.4 N.A with iris diaphragm, swing out filter holder and phase annulus ring slot with ring centering knobs. All steel rack and pinion gears ensure precise centering. Illumination is powered by 6V20W halogen with variable controls.

Accessories of Omano OM900-T Inverted Trinocular Biological Microscope

23mm smooth trinocular adapter, blue, green and frosted white filters, manual, dust cover.
Shipping Wt. and dimensions: 25 Lb. 20″x15″x11″.
