Harga Jual SEW Analogue (1kV below) Insulation Testers 8031 IN

Kode : 8031 IN
Berat : 500 gram
Stok : Ready Stock
Kondisi : Baru
Kategori : Alat Ukur
Dilihat : 1.308 kali
Review : Belum ada review
Hubungi kami secara langsung untuk pemesanan yang lebih cepat!
Harga Jual SEW Analogue (1kV below) Insulation Testers 8031 IN

*Pemesanan dapat langsung menghubungi kontak di bawah ini:

Review Spesifikasi danHarga Jual SEW Analogue (1kV below) Insulation Testers 8031 IN original termurah dan bergaransi resmi *Harga Hubungi CS
Ready Stock / 8031 IN
INFO HARGA
Silahkan menghubungi kontak kami untuk mendapatkan informasi harga produk ini.

Bagikan informasi tentang Harga Jual SEW Analogue (1kV below) Insulation Testers 8031 IN kepada teman atau kerabat Anda.

Deskripsi Harga Jual SEW Analogue (1kV below) Insulation Testers 8031 IN

http://www.sew.com.tw/ezfiles/sew1/img/img/174695/banner2.png

FEATURES
● High quality Taut Band movement.
● Three insulation test voltages(DC) : 250V, 500V, 1000V.
● Two continuity test on “low ohms” : 2Ω & 20Ω.
● AC voltmeter with linear scale up to 600 Vac.
● 200mA short circuit current for continuity.
● 1mA test current on insulation test at nominal voltage.
● Automatic discharge of capacitive and inductive circuit with charge stored in the circuit under test.
● Live warning and display of external voltage presence.
● Fuse, air gap, crowbar and overload protected.
● On line battery monitoring shows if battery is ok.
● Manual zero ohm adjustment.
● Low battery consumption.
● Mirror scale.
● Push and turn locking switch for continuous and hand free testing.
● Supplied with high quality test leads.
● BS 16 edition.
  SPECIFICATIONS


Insulation Resistance
Test voltage (DC V) 250V     /   500V   /   1000V
Output voltage on
open circuit
Rated test voltage +10%
Measuring ranges 0-100MΩ / 0-200MΩ / 0-400MΩ
Mid-scale value 1MΩ     /   2MΩ     /     4MΩ
Scale multiplier ×1/2     /     ×1       /       ×2
Accuracy ± 5% of full scale
Output short-
circuit current
≥ 1.0mA
Continuity
Measuring ranges 2Ω / 20Ω
zero Ω adjustment by knob ˇ
Output short-
circuit current
≥ 200 mA
Accuracy ± 1.5% of scale length
AC Voltage
Range 0-600V AC
Accuracy ± 3% of scale length
General
Voltage warning Warning light circuit live lit From 90Vdc /
70Vac, Buzzer beep from 24V ac/dc
Dimensions 221(L) × 110(W) × 56.8(D)mm
Weight
(battery included)
Approx. 600g
Power source 1.5V (AA) × 6
Safety standard EN 61010-1 CAT III 600V
EN 61326-1

8031
